Desktop Automatic Flat Labeling Machine

Description

Features

1.Adopt mature technology Panasonice PLC control system, USA Hypsen sensor.
operation is stable and high-speed
2.Using touch-screen control operating system, simple, practical, efficient;
3.Adapt variety shape of object in top labeling;
4.Screw adjustment to suppress body movements accurately;
5.Synchronization chain mechanism ensure labeling smooth and precise calibration;
Parameter
1.Label width: 10-120mm ( back paper : 120mm)
2.Label length:10-200mm
3.Products Size:
L:40-300mm
W:40-200mm
H:5-120mm
4.Max Outside diameter of label roll: φ260mm
5.Inside diameter of label roll: φ76mm
6.Max Labeling speed: 50-100pcs /min
7.Accuracy of labeling:±1mm
8.Power: 220V/110V 50/60Hz
9.Machine Net Weihgt : 100KG

10. Machine dimension: 1200mm×600mm×980mm(LxWxH)
