High Speed Flat Screen Printing Machine with Auto Manipulator

Description

Application
Soft and thin products such as paper, plastics film ;signs and panels, textiles,garments, plastic sheets, Metal sheet,glass sheet and advertising materials, printed circuits, light boxes and so on
Feature
Metal Sheet Screen Printing Machine with Auto sucker manipulator  adopts Mechanical cam separator from Taiwan to make rotary table. The Flat Silk Screen Printer is rotating with stability while proceeding with uploading and downloading the products during printing,with which the machine could work continuously.
Function
1. SCM IC coordinates light-touch panel to compile programmable actions.
2. Auto 4-digit conter built-in to calculate printing quantity
3. Airframes adopts aluminum casting and with metal coating surface
4. Double cylinders up& down structures ensures printing precisions and stability
5. Left & right stroke, squeegee and ink tool positions could be adjusted
6. Pneumatic squeegee constant pressure device ensures the pressure stability during processing.
7. T-slot worktable brings convenience to load and unload jig
8. Up&down are equiped with Taiwan CEC oil pressure buffer to eliminate working shock.
Parameters
Model  No.:ECHP-3565C
Max Printing Area:650x350mm
Max Screen Frame: 800x 450mm
Printing Height:0-130mm
Working tabel Vertical&horizontal adjust: 10mm
Air Pressure:5-6 bar
Printing Speed: 800-1200pcs / hour
Machine Dimension: 145x115x157cm
GW:350kG

Power: 220V  single phase
