LPG Gas Tank Screen Printing Machine

Description

This machine is designed to LPG Gas Tank printing , it's electric motor driven to print , more stable .

Feature
1. Advanced fully automatic computerized system control,easy handing .
2. Built-in four figures automatic LED digital counter
3. Suitable for printing on round, cylindrical, oval or flat project
4. Light-weight, strong aluminum cast machine frame, Adujustability of routs and speeds
5. Automatic oil scrabbing, oil return and lifting table
6. Squeegee/flood bar depth, pressure, speed, leveling, and stroke etc., are all adjustable to fit your various printing needs.
7. Horizontal movement of screen frame can be adjusted to fit your various printing needs.
8. Net frame work table can be adjusted around emblem, tone down logo, printing, high precision, easy to adjust ,quick.
9. Adopt USA Parker or Japan SMC components.

Specifications
1 Max printing diameter: Φ375 mm
2. Max Printing area：420×1170mm
3. Max gradient for Work piece：14°
4. Air pressure：6 Bar
5. Air consumption：600 liter/min
6. Power voltage: AC 110V/220V
7. Power consumption：50 W
8. Machine dimension：1720×1600×1650mm

9. Machine weigh: 330 kg
