Two Color turntable flat screen printing machine

Description

The machine with 3 Mitsubishi servo motors, use printing head up

and down use Festo cylinder, 2 LED UV drying system

Machine information:

Machine overview: two-color turntable flat screen printing machine
Action mode: Fully automatic mi-automatic
Start mode: touch screen +buttons
Printing up and down power: FESTO cylinder
Printing left and right power: Mitsubishi servo motor*2
Cutting module power: Mitsubishi  servo motor
Performance introduction:

Programmable Controllers
Automatic digital counter to count the printing quantity
Printing action design multiple printing cycles
Channel steel, Fangtong rice gold body, surface metal paint
The mesh arm can be fine-tuned front and rear, left and right, and multi-directional adjustment
The whole machine runs fast, stable and low noise
Fast speed and simple operation
Precision and stability
Simple conversion fixture
Quickly adjust and change products
Wide range of applications

This machine is suitable for flat screen printing process

Printing speed	1000-1200 times/hour
Power supply	220V50HZ-60HZ/800W
Air pressure	0.5MPA
Maximum screen frame size	380X600MM
Maximum printing area	200X400MM
Maximum product height	0-100MM
Machine size	Length 1650, width 1650MM, height 1700MM
table diameter	1500MM (8 position)
